AP-702CF
Advantage
- Soft, pliable, and tough
- Exceptional stability in extremely low temperature
- Low compression set
- Excellent thermal insulation
- Can be in roll
- Resistant to most chemicals, petroleum products, and humidity, will not rot.
- Impact cushioning
- Not include CFC ozone depletion materials & free of 10 Phthalates
(DBP,BBP,DENP,DINP,DNHP,DIBP,DNPP,DCHP,DIDP,DNOP)
Application
- Qualified passing UL94 as thermal insulation and buoyancy material for survival suits, foul-weather gear and wearing apparel.
- Cushioning material
- Widely using in home appliance field.
Fabrication
Cutting, die-cutting
Adhesive bonding, welding
Sewing, stitching
Specification
| Units | Test Method | AP-702CF | |
| Density (P.C.F) | lb/ft3 g/cm3 |
3.5-5.0 0.06-0.08 |
|
| Water Absorption (Vacuum Method) | Wt%Max | ASTM D1056-14 |
8 |
| Compression deflection(25%) |
lb/in2 kg/cm2 |
ASTM D1056-14 |
1.5-4.0 0.11-0.28 |
| Compression set (50%) |
%Max | ASTM D1056-14 |
20 |
| Tensile Strength | lb/in2 kg/cm2 |
ASTM D412-16 |
50 3.5 |
| Elongation | %Min | ASTM D412-16 |
230 |
| Thermal conductivity 75°F(24°C) |
BTU.in/hr. sqft. °F Max | ASTMC 177-19 |
0.27 |
| Flammability |
ASTM D1692 | Self-extinguishing |
ASTM method, in some cases, may be modified slightly to make results more meaningful for end-use application.
