NV-815S

https://foam.winboss.com/web/image/product.template/148/image_1920?unique=32454d2

Advantage

  • Low G’s value, low rebound and penetration
    【G’s value】Maximum G’s is the largest deceleration experienced by the impact penetrating into the foam. The greater the G‘s value the more serious and damaging the impact for the same time duration.
    【Rebound】The significance of a low rebound it indicates the foam has absorbed a large amount of the initial impact energy. High rebound is detrimental because of the snap-back effect.
  • Under strong re-impacting, still have the excellent compression set and will not change its shape
  • The excellent state of stability is built on its cold-resisting and heat-resisting ability
  • Resistant to most chemicals, petroleum products, and humidity, will not rot.
  • Not include CFC ozone depletion materials (tested by TÜV, Germany) & Free of 10 Phthalates (DBP,BBP,DENP,DINP,DNHP,DIBP,DNPP,DCHP,DIDP,DNOP)
  • Meet EN13158 and EN1621 requirement
  • Easy to clean
  • Self -extinguishing

    This combination does not exist.

    Application

    • Excellent shock-absorbing material for ice hockey, equestrian, sporting protectors, inner shoes, motorcycle body protectors.

    Specification

    Units Test Method NV-815S
    Density lb/ft3
    g/cm3

    11.2 ~ 13.7
    0.18-0.22
    Water Absorption Wt%Max ASTM D1056-14
    5
    Compression Set (50%)
    %Max
    ASTM D1056-14
    10
    Compression Deflection(25%)
    lb/in2
    kg/cm2
    ASTM D1056-14
    9.0-12.0
    0.63-0.84
    Tensile Strength
    lb/in2
    kg/cm2
    ASTM D412-16
    340
    24
    Elongation
    %Min.
    ASTM D412-16
    300
    Percent Rebound
    %
    ASTM-F355
    <5

    ASTM method, in some cases, may be modified slightly to make results more meaningful for end-use application.
