Insulation Cushion Foam
Application
- Mostly used for knee pad / garden pad in industrial fields.
- Cushioning material.
Advantage
- Soft, pliable, and tough.
- Exceptional stability in extremely low temperature.
- Low compression set.
- Excellent thermal insulation.
- Self-extinguishing.
- Resistant to most chemicals, petroleum products, and humidity, will not rot.
- Impact cushioning.
- Not include CFC ozone depletion materials (tested by TÜV, Germany) & Free of 10 Phthalates. (DBP,BBP,DENP,DINP,DNHP,DIBP,DNPP,DCHP,DIDP,DNOP)
Fabrication
- Cutting, die-cutting.
- Adhesive bonding, welding.
| Standard Sheet Size | Units | Test Method |  AP-702CF |  TAPE |  NV-904S |  NV-904C |  NV-400C |
| Standard Sheet Size | in cm | 48x72 120x182 | 42x72 106x182 | 36x54 91x137 | 36x84 91x213 | 24x72 60x180 |
|
| Standard Roll Width |
in cm | 48/56 120/142 | 42 106 | 36 91 | |||
| Max. Gauge | in cm | 1.25 30 | 0.25 7 | 1 25 | 1 25 | 0.75 20 | |
| Colors (other colors available) | Blk* | Blk | Blk* | Nat/Blk | Red/Green/BLue | ||
| Density (P.C.F) | lb/ft3 g/cm3 | 3.5-5.0 0.06-0.08 | 5.5-7.0 0.09-0.12 | 7.5-9.5 0.12-0.15 | 7.5-9.5 0.12-0.15 | 3.7-5.6 0.06-0.09 | |
| Compression Deflection (25%,Psi) | lb/in2 kg/cm2 | ASTM D1056 | 1.5-4.0 0.11-0.28 | 2.5-5.0 0.18-0.35 | 3.5-5.0 0.25-0.35 | 3.5-5.0 0.25-0.35 | 3.0-5.0 0.21-0.35 |
| Compression Set (50%) | %Max | ASTM D1056 | 20 | 20 | 15 | 15 | |
| Water Absorption (Vacuum Method) | Wt%Max | ASTM D1056 | 8 | 5 | 5 | 8 | 8 |
| Water Absorption | Ibs/Sq.Ft | ASTM D1667 | 0.1 | 0.1 | 0.1 | 0.1 | |
| Heat Aging (7 Days @ 158°F ) Lineal Shrinkage | %Max | ASTM C548 | 5 | 5 | 5 | 5 | 5 |
| Tensile Strength | lb/in2 kg/cm2 | ASTM D412 | 50 3.5 | 100 7 | 90 6.5 | 100 7 | 55 4 |
| Elongation | %Min | ASTM D412 | 230 | 320 | 350 | 350 | 180 |
| Thermal Coductivity 75 °F(24 °C) | BTU.in/hr. sqft. °F Max | ASTM C177 | 0.27 | 0.31 | 0.31 | 0.31 | |
| Specification | ASTM D1056-68 ASTM D1056-91 | SCE-41 2C1 | SCE-41 2C1 | SCE-41 2B1 | SCE-41 2B1 | SCE-41 2C1 |
UL Approved Flame Resistance Foam (E238526 – Plastics – Component)
ULC Approved Flame Resistance Foam (E238526 – Plastics Certified for Canada – Component)
Gel Foam
Application
- Soft medical cushions & protectors
- Sporting protectors and pads
- Saddles
- Glove
- Insoles
Advantage
- Soft, pliable, and tough
- Light weight
- Super impact cushion
- Excellent thermal insulation
- Self-extinguishing
- High resistance against heat, cold, humidity, mildew, and rotting as well as against most oils and chemicals, thereby guaranteeing durability.
- High resistance against bacteria
- Not include CFC ozone depletion materials (tested by TÜ V, Germany)
- No irritation to skin; easy to clean
Fabrication
Winboss Gel-Foam can be fabricated in many ways using conventional machines and equipment by:
- Cutting, Die-Cutting
- Adhesive Bonding, Welding
- Sewing, Stitching
Typical Physical Properties and Characteristics of Winboss Gel-Foam: G-20
| Standard Sheet Size | Units | Test Method | G-20 |
| Density |
lb/ft3 g/cm3 | 7.0-9.4 0.11-0.15 |
|
| Water Absorption |
Wt%Max | ASTM D1056 | 5 |
| Compression Deflection (25%) | lb/in2 kg/cm2 | ASTM D1667 | 3-4.5 0.21-0.32 |
| Tensile Strength | lb/in2 kg/cm2 | ASTM D412 | 70 5 |
| Elongation | %Min | ASTM D412 | 350 |
| Compression Set (50%) | ASTM D1056 | 10 |
ASTM method, in some cases, may be modified slightly to make results more meaningful for end-use application.
|
|
|
|
|
|
|
|
