AP-702CF

https://finishedproducts.winboss.com/web/image/product.template/137/image_1920?unique=d72f21f

Advantage

  • Soft, pliable, and tough
  • Exceptional stability in extremely low temperature
  • Low compression set
  • Excellent thermal insulation
  • Can be in roll
  • Resistant to most chemicals, petroleum products, and humidity, will not rot.
  • Impact cushioning
  • Not include CFC ozone depletion materials & free of 10 Phthalates
    (DBP,BBP,DENP,DINP,DNHP,DIBP,DNPP,DCHP,DIDP,DNOP)

    This combination does not exist.

    Application

    • Qualified passing UL94 as thermal insulation and buoyancy material for survival suits, foul-weather gear and wearing apparel.
    • Cushioning material
    • Widely using in home appliance field.

    Fabrication

    Cutting, die-cutting

    Adhesive bonding, welding

    Sewing, stitching

    Specification

    Units Test Method AP-702CF
    Density (P.C.F) lb/ft3
    g/cm3
    		3.5-5.0
    0.06-0.08
    Water Absorption (Vacuum Method) Wt%Max ASTM D1056-14
    		 8
    Compression deflection(25%)
    		 lb/in2
    kg/cm2
    		 ASTM D1056-14
    		 1.5-4.0
    0.11-0.28
    Compression set (50%)
    		 %Max ASTM D1056-14
    		 20
    Tensile Strength lb/in2
    kg/cm2
    		 ASTM D412-16
    		 50
    3.5
    Elongation %Min ASTM D412-16
    		 230
    Thermal conductivity 75°F(24°C)
    		 BTU.in/hr. sqft. °F Max ASTMC 177-19
    		 0.27
    Flammability
    		 ASTM D1692 Self-extinguishing

    ASTM method, in some cases, may be modified slightly to make results more meaningful for end-use application.
